Zero Spillover Jamming

RF-JAM ZERO

Total Signal Denial. Zero External Impact.

The first intelligent jamming system that solves the short blanket problem. ML-powered calibration delivers maximum signal denial inside your facility with guaranteed zero spillover outside.

The Innovation

Intelligent Jamming That Adapts in Real-Time

Instead of setting power levels once and hoping for the best, RF-JAM ZERO continuously measures and adapts:

The Innovation: External Sensor Network + ML Optimization

Step 1

External Sensors placed outside the facility perimeter continuously measure RF levels

Step 2

ML Algorithm analyzes sensor data and jammer telemetry in real-time

Step 3

Per-Module Optimization adjusts power levels for each individual module

Step 4

Continuous Loop repeats every 1-5 seconds, adapting to changing conditions

The Result

  • Maximum jamming where it's needed (inside the facility)
  • Zero spillover where it's prohibited (outside the perimeter)
  • Automatic compliance with all regulatory requirements

Complete Communication Denial

RF-JAM ZERO blocks all wireless communication technologies that could be exploited:

Cellular Technologies

2G GSMBlocked
3G UMTS/HSPABlocked
4G LTEBlocked
5G NRBlocked

WiFi Technologies

WiFi 2.4 GHzBlocked
WiFi 5 GHzBlocked
UHFOptional
Additional BandsConfigurable

Protected (Not Blocked)

Emergency ServicesProtected

911 and equivalent must work

TETRA/Police RadioProtected

Law enforcement communications

Facility RadioProtected

Internal security communications

System Design

Modular, Redundant, Maintainable

Inhibition Units

8-Module Primary Units

  • Power per module: 20-30W
  • Bands covered: 8 simultaneous
  • Hot-swap capability
  • IP54+ vandal-resistant
  • Forced air cooling

4-Module Secondary Units

  • For targeted coverage areas
  • Same power and quality specifications
  • Used for specific zones or extensions

External Sensor Network

Continuous spillover measurement

  • Quantity: 8-12 sensors perimeter
  • Location: OUTSIDE facility geofence
  • Measurement: All blocked frequency bands
  • Communication: Wired or dedicated wireless
  • Reporting: Every 1-5 seconds

The sensors must be outside to measure what escapes. Inside sensors would only measure the jamming signal—not the spillover.

ML Calibration Engine

Optimize power levels automatically

Algorithm

  • Input: Sensor readings + jammer telemetry
  • Processing: Gradient descent optimization
  • Output: Per-module power setpoints
  • Constraint: RF at all sensors ≤ regulatory limit
  • Objective: Maximize effective jamming coverage

Adapts To

  • Weather changes (humidity affects RF propagation)
  • Building occupancy changes
  • Equipment aging compensation
  • Seasonal variations

Central Control System

Dashboard Features

  • Real-time status of all modules
  • Spillover heat map visualization
  • Power level monitoring
  • Alert management
  • Scheduling and programming
  • User and role management
  • Complete audit logging

Controls

  • Individual module ON/OFF
  • Zone-based control
  • Time-based scheduling
  • Manual power override (with safety limits)
  • Emergency shutdown
Regulatory Assurance

Guaranteed Compliance

Continuous Monitoring

Every second, external sensors verify that spillover remains below regulatory thresholds. If any sensor detects elevated levels, the system automatically reduces power.

Evidence Documentation

  • All sensor readings with timestamps
  • All power level changes with reasons
  • System events and alerts
  • Operator actions

Audit-Ready Reports

  • Historical spillover levels (always compliant)
  • System operation logs
  • Maintenance records
  • Any anomalies and resolutions

Regulatory Support

  • Documentation formatted for regulatory submissions
  • Technical data for permit applications
  • Ongoing compliance evidence

100% Compliance Guarantee

Every second, external sensors verify regulatory compliance. Zero spillover, guaranteed.

Technical Overview

Technical Specifications

Technical Equipment

Inhibition Units

Modules (Primary)8
Modules (Secondary)4
Power per Module20-30W ±1.5dB
Power Regulation3 levels (low/med/high)
Hot-SwapYes
ProtectionIP54+
Operating Temp-10°C to +55°C
HumidityUp to 90%
CoolingForced air
Operation24/7 continuous

What Makes RF-JAM ZERO Different

Traditional Jammers

  • Set power levels manually
  • Static configuration
  • Compromise between coverage and spillover
  • Periodic adjustment required
  • Compliance depends on initial setup

Coverage OR Compliance - pick one

RF-JAM ZERO

  • ML-optimized power levels
  • Dynamic configuration every 1-5 seconds
  • No compromise: maximum coverage + zero spillover
  • Automatic adaptation to conditions
  • Continuous compliance verification

Coverage AND Compliance - guaranteed

Deployment

Implementation Process

1

Site Survey

  • Facility layout analysis
  • RF environment mapping
  • Perimeter assessment
  • Regulatory requirements review
2

System Design

  • Module placement optimization
  • Sensor network design
  • Coverage simulation
  • Integration planning
3

Installation

  • Hardware deployment
  • Sensor network installation
  • Network configuration
  • Initial calibration
4

ML Training Period

  • System learning phase
  • Optimization tuning
  • Performance validation
  • Coverage verification
5

Training

  • Operator training
  • Administrator training
  • Compliance procedures
  • Maintenance protocols
6

Go-Live

  • Full system activation
  • Continuous monitoring begins
  • Support transition
  • Documentation handover

Typical deployment timeline: 4-8 weeks depending on facility size and complexity

Frequently Asked Questions

Eliminate Unauthorized Communications

Request a demonstration to see how RF-JAM ZERO can provide complete signal denial with zero regulatory risk.

Related Product

IMSI-TRACK PRO

When you need intelligence, not just blocking. See every device, know every identity.
